Landing Operating Panel (LOP)

The Landing Operating Panel (LOP) is an essential control interface located on each elevator landing or floor. It allows users to call the elevator to their desired floor and indicates the car’s position and direction. Designed with precision and durability, the LOP ensures smooth operation and reliable communication between passengers and the elevator system.

Specification	Details
Product Type	Landing Operating Panel (LOP)
Button Type	Mechanical Push Buttons / Piezo / Vandal-Resistant
Display Options	LED / LCD / Dot Matrix / Seven Segment Indicator
Material	Stainless Steel SS304 / SS316 / Glass / Acrylic
Finish Options	Hairline Finish, Mirror Finish, Titanium Coating
Backlight	LED-illuminated buttons (White/Blue/Custom)
Intercom/Call Function	Up/Down Call Buttons (or Single Call Button)
Braille Support	Available on request
Mounting Type	Flush Mount / Surface Mount
Voltage Requirement	12V / 24V DC
Communication	Serial / Parallel / CANBUS (Model dependent)
Operating Temperature	-10°C to 55°C
Protection Level	IP32 – IP54 (Depending on design)
Durability	Scratch-resistant and corrosion-resistant
Panel Size	Customizable as per landing door size and requirements
Application	Passenger, Hospital, Goods, MRL & Commercial Elevators
Compliance	EN81 / ADA / IS Standards (On Request)

Type: Parts
